LT3091HT7#PBF

SKU: 87166

Manufacturer: Analog Devices

LDO Regulator Neg 0V to -32V 1.5A Automotive 7-Pin(7+Tab) TO-220 Tube

3750 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
SVHC	Yes
SVHC Exceeds Threshold	Yes
Automotive	No
PPAP	No
Type	LDO
Number of Outputs	1
Polarity	Negative
Accuracy (%)	±1
Output Type	Adjustable
Output Voltage (V)	0 to -32
Maximum Output Current (A)	1.5
Minimum Input Voltage (V)	-36
Maximum Input Voltage (V)	-1.5
Maximum Dropout Voltage @ Current (V)	0.42@1.5A
Line Regulation	2.5uV/V(Typ)
Load Regulation	2nA(Typ)
Maximum Quiescent Current (mA)	0.001
Junction to Ambient	34°C/W
Junction to Case	3°C/W
Special Features	Current Limit
Operating Temperature-Min	-40
Operating Temperature-Max	150
Supplier Temperature Grade	Automotive
Packing Method	Tube
Original Package	TO-220
Pin Count	7
Standard Package Method	TO-220
Terminal Form	Through Hole
Package Height	9.4(Max)
Package Length	10.54(Max)
Package Width	4.57(Max)
PCB changed	7
Tab	Tab
