ADSP-2191MKCAZ-160

SKU: 30039

Manufacturer: Analog Devices

DSP Fixed-Point 16bit 160MHz 144-Pin Mini-BGA Tray

2020 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	3A991a.2.
Part Status	NRND
HTS	8542.31.00.01
Automotive	No
PPAP	No
Family Name	ADSP-219x
Numeric and Arithmetic Format	Fixed-Point
Data Bus Width (bit)	16
Program Memory Type	ROMless
RAM Size	160KB
Programmability	No
Interface Type	SPI/UART
Number of I/Os	16
Device Input Clock Speed (MHz)	160
USART	0
UART	1
USB	0
SPI	2
I2C	0
I2S	0
CAN	0
Ethernet	0
Operating Supply Voltage-Min (V)	2.37
Typical Operating Supply Voltage (V)	2.5
Operating Supply Voltage-Max (V)	2.63
Operating Temperature-Min	0
Operating Temperature-Max	70
Supplier Temperature Grade	Commercial
Packing Method	Tray
Original Package	Mini-BGA
Pin Count	144
Standard Package Method	BGA
Terminal Form	Surface Mount
Package Height	0.85(Min)
Package Length	10
Package Width	10
PCB changed	144
