ADR130BUJZ-REEL7

SKU: 116650

Manufacturer: Analog Devices

V-Ref Programmable 0.5V/1V 4mA 6-Pin TSOT T/R

2240 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Reference Type	Programmable
Topology	Series
Initial Accuracy	0.35%
Maximum Temperature Coefficient	25ppm/°C
Load Regulation	2mV/mA
Line Regulation	40ppm/V
Output Voltage (V)	0.5/1
Maximum Input Voltage (V)	20
Maximum Output Current (mA)	4
Operating Temperature-Min	-40
Operating Temperature-Max	125
Supplier Temperature Grade	Industrial
Packing Method	Tape and Reel
Pin Count	6
Standard Package Method	SOT
Original Package	TSOT
Terminal Form	Surface Mount
Package Height	0.87
Package Length	2.9
Package Width	1.6
PCB changed	6
