AD8804ARUZ-REEL

SKU: 79409

Manufacturer: Analog Devices

DAC 12-CH R-2R 8-bit 20-Pin TSSOP T/R

2950 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Converter Type	General Purpose
Architecture	R-2R
Resolution	8bit
Conversion Rate	1.7Msps
Number of DAC Channels	12
Number of Outputs per Chip	12
Maximum Settling Time (us)	0.6(Typ)
Digital Interface Type	Serial (3-Wire, SPI)
Output Type	Voltage
Output Polarity	Unipolar
Voltage Reference	External
Minimum Single Supply Voltage (V)	2.7
Typical Single Supply Voltage (V)	3
Maximum Single Supply Voltage (V)	5.5
Power Supply Type	Single
Maximum Power Dissipation (mW)	0.055
Integral Nonlinearity Error	±1.5LSB
Full Scale Error	±1LSB
Digital Supply Support	No
Operating Temperature-Min	-40
Operating Temperature-Max	85
Packing Method	Tape and Reel
Pin Count	20
Standard Package Method	SOP
Original Package	TSSOP
Terminal Form	Surface Mount
Package Height	1.05(Max)
Package Length	6.5
Package Width	4.4
PCB changed	20
