AD7606C-18BSTZ

SKU: 157382

Manufacturer: Analog Devices

8-Channel Octal ADC SAR 1Msps 18-bit Parallel/Serial (3-Wire, SPI) 64-Pin LQFP Tray

4380 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Active
HTS	8542.39.00.01
Automotive	No
PPAP	No
Converter Type	General Purpose
Architecture	SAR
Resolution	18bit
Number of ADCs	8
Number of Input Channels	8
Sampling Rate	1Msps
Digital Interface Type	Parallel
Input Type	Voltage
Input Signal Type	Single-Ended
Voltage Reference	Internal
Polarity of Input Voltage	Unipolar
Voltage Supply Source	Single
Input Voltage	5V/10V/12.5V
Minimum Single Supply Voltage (V)	4.75
Typical Single Supply Voltage (V)	5
Maximum Single Supply Voltage (V)	5.25
Maximum Supply Current	50
Typical Power Dissipation (mW)	245
Maximum Power Dissipation (mW)	272
Integral Nonlinearity Error	±7LSB
Full Scale Error	±140LSB
Signal to Noise Ratio	102dB(Typ)
No Missing Codes (bit)	18
Sample and Hold	Yes
Single-Ended Input	Yes
Digital Supply Support	No
Operating Temperature-Min	-40
Operating Temperature-Max	125
Packing Method	Tray
Original Package	LQFP
Pin Count	64
Terminal Form	Surface Mount
Package Height	1.4
Package Length	10
Package Width	10
PCB changed	64
