BTFW16R-3RSTE1LF

SKU: 53708

Manufacturer: Amphenol ICC

Conn Board to Board RCP 16 POS 1mm Solder RA SMD T/R

3230 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant
ECCN (US)	EAR99
Part Status	Obsolete
Automotive	No
PPAP	No
Type	Board to Board
Gender	RCP
Number of Contacts	16
Number of Rows	2
Termination Method	Solder
Terminal Pitch (mm)	1
Body Orientation	Right Angle
Current Rating-Max(A)	1/Contact
Voltage Rating-Max	100VAC
Insulation Resistance (MOhm)	1000
Maximum Contact Resistance (mOhm)	70
Operating Temperature-Min	-55
Operating Temperature-Max	85
Packing Method	Tape and Reel
Length (mm)	23
Depth (mm)	10
Height (mm)	7.6
