AZ2150-1A-12DEF

SKU: 109886

Manufacturer: American Zettler, Inc

Power Relay 12VDC 40A SPST-NO(31.8x26.9x19.1)mm THT

13950 parts IN STOCK

Shipped from :

Netherlands

Expected Ships :

Rohs State : Need to verify

Increments of 0 pcs

Products specifications

EU RoHS	Compliant with Exemption
ECCN (US)	EAR99
Part Status	Active
HTS	8536.41.00.50
Automotive	No
PPAP	No
Contact Arrangement	SPST-NO
Contact Form	1 Form A
DC Coil Voltage (V)	12
Coil Current (mA)	77.42
Coil Resistance (Ohm)	155
Insulation Resistance (MOhm)	1000
Maximum Contact Resistance (mOhm)	<20
Maximum Pick-Up Voltage	9VDC
Minimum Dropout Voltage	>1.2VDC
Maximum AC Switching Voltage (V)	300
Maximum DC Switching Voltage (V)	30
Maximum Switching Current (A)	40
Maximum Switching Power	900W
Operate Time (ms)	12
Release Time (ms)	5
Electrical Life (Operations)	100000
Mechanical Life (Operations)	10000000
LED Indicator	No
Push to Test Button	No
Coil Suppression Diode	No
Relay Construction	Non-Latching
Terminal Form	Through Hole
Terminal Form	PC Pin
Number of Terminals	4
Operating Temperature-Min	-55
Operating Temperature-Max	105
Product Weight (g)	25
Length (mm)	31.8
Depth (mm)	26.9
